S-1001 (Metallic only)
This top-grade compressed gasket sheet material is made primarily of high-grade chrysotile asbestos fibers and NBR binders, reinforced with close steel wire gauze insertion.
Technical Description
Compliance: IS 2712 Grade W/ 1
Identification Colours: Black Graphited. Optional Steel Wire Mesh Insert available with Graphite Finish
Suitable for: Extremely demanding sealing applications for stability at High Fluctuating temperatures and pressures. Would be an excellent and economical choice for Sugar Plants/ Boiler Engineers.
Appropriate Medium: Steam, Oxygen, Petroleum Distillates, Hot Oils, Tar Oils, Hydrocarbons, Lyes etc. Motor Oil, Transmission and Hydraulic Fluids, Steam, Alkalies, Antifreeze and Refrigeration Oils. (High Service conditions)
Specification
| Property | Metallic |
|---|---|
| Continuous Temperature | 600 ºC |
| Recommended Maximum Pressure | 200 kg/cm2 |
| Sheet Size | 1600 x 4500/1500 x 6000/1500 x 1600/1500 x 1500/1500 x 2000/1500 x 3000/2000 x 6000/3000 x 3000mm |
| Thickness | 0.50 to 6.00mm |
